Sheath thermocouple ANDMTE passive sensor for temperature measurements between -220 and +1150°C in liquid or gaseous media. Because of their special interior design with magnesium oxide, thermocouple elements can be used for applications with high pressure and vibrations while guaranteeing a long life span. Sheath Thermocouples are bendable and have a fast response time. The ANDMTEs are installed with the help of screw clamps.
Additional options for sensor ANDMTE (surcharges):
- additional cable length – surcharge per meter.
Sensor type:
- Passive sensor
Product number – Sheath thermocouple
Product number: ANDMTE
Technical Specifications – Sheath thermocouple
| Thermocouple: | NiCr-Ni Type K acc. to DIN IEC 584 – isolated |
| Diameter: | 1 mm, 1,5 mm, 3 mm and 6 mm |
| Fitting length: | 100 mm, 150 mm, 200 mm, 300 mm, 500 mm |
| Material: | Inconel – 2.4816 |
| Connective sleeve: | 8 x 40 mm, diameter 6 mm / all others 5 x 35 mm |
| supply cord: | Glass fiber with stainless steel coating 2 x 0.22 mm² |
| Length of supply cord: | 2,000 mm (standard) |
| Terminal connection: | 50 mm loose ends with core-end sleeves |
| Protection class: | IP54 |
| Max. operating temp. MTE: | -220 °C … +1150 °C |
| Max. operating temp. cable: | -50 °C … +400 °C |
Here you can find, a summary of temperature scaling based on electrical resistance.
Datasheet ANDMTE
TALK TO AN EXPERT
Interested in our products? Looking for options or a specific quote? Contact us with your custom enquiry!
Versions of ANDMTE
| Diameter | 100mm | 150mm | 200mm | 300mm | 500mm |
| 1,0mm | ANDMTE1.0/100/2m | ANDMTE1.0/150/2m | ANDMTE1.0/200/2m | ANDMTE1.0/300/2m | ANDMTE1.0/500/2m |
| 1,5mm | ANDMTE1.5/100/2m | ANDMTE1.5/150/2m | ANDMTE1.5/200/2m | ANDMTE1.5/300/2m | ANDMTE1.5/500/2m |
| 3,0mm | ANDMTE3.0/100/2m | ANDMTE3.0/150/2m | ANDMTE3.0/200/2m | ANDMTE3.0/300/2m | ANDMTE3.0/500/2m |
| 6,0mm | ANDMTE6.0/100/2m | ANDMTE6.0/150/2m | ANDMTE6.0/200/2m | ANDMTE6.0/300/2m | ANDMTE6.0/500/2m |
How to order?
Order example: ANDMTE thermocouple ø 3.0mm, fitting length 200 mm, cable length 3000 mm = ANDMTE 3.0 / 200 / 3m
