Alledio BACnet Presence Sensor ANB-P is an occupancy/presence sensor for reliable detection of people in indoor spaces, providing a clear “detected/undetected” (1/0) signal within a range from 1.0 m to 10.5 m. This presence device supports both BACnet MSTP and BACnet IP communication protocols, ensuring easy integration into modern Building Management Systems.
The ANB-P is designed for building automation in living and office spaces, reception halls, foyers, hotels, industry and other commercial environments where accurate presence detection is required for lighting and HVAC control – air conditioning operates only when the space is actually occupied.
Communication protocols supported in ANB-P:
- BACnet MSTP
- BACnet IP
- Modbus RS485
Alternative BACnet sensor versions:
- ANB-T – Bacnet temperature sensor
- ANB-TH – Bacnet temperature, humidity sensor
- ANB-THPV – Bacnet temperature, humidity sensor, pressure, VOC
- ANB-THPC – Bacnet temperature, humidity sensor, pressure, CO2
- ANB-THPVC – Bacnet temperature, humidity sensor, pressure, CO2, VOC
- ANB-THPVCP – Bacnet multi sensor: temperature, humidity sensor, pressure, CO2, VOC, presence
- ANB-THPM2.5– Bacnet temperature, humidity, particulate matter – PM2.5
Color Variations
white sensor case
black sensor case
Video
Product number
Product number: ANB-P
Technical Specifications for BACnet Presence Sensor
| Power Supply | AC: 24 VAC DC: 12-35 V; max expected power: 1,1W |
| Communication Protocols | BACnet MSTP BACnet IP Modbus RS485 |
| Measuring Ranges | Presence: detected / undetected (1/0), detection range from min 1.0 m to max 10.5 m |
| Power Supply Cable | Screened, twin twisted pair 0.75mm to 1mm. Screen earthed at controller end only. |
| Connections | Pluggable screw terminals for 0.3 to 1.5mm cable |
| Communication Cable | Twisted pair with drain wire and foil wrap or equivalent. Must be suitable for RS485 Standard. |
| Ingress Protection | IP30 |
| Ambient condition | From -10°C to +50°C, max 85%rH non-condensing |
| Product dimensions | 87 mm × 87 mm × 19 mm |
| Product weight | 55 g |
| Package dimensions | 115 mm x 115 mm x 42 mm (protective case) |
| Country of origin | Slovenia, EU |
| Warranty | 1 year |
BACnet Presence Sensor Commissioning
Setting up the sensor is remarkably straightforward. Simply tap the sensor with your smartphone to automatically launch a mobile web app in your browser. This allows you to configure all necessary Modbus or BACnet settings effortlessly, eliminating the need for fiddling with small DIP switches. The intuitive process ensures the sensor is ready for seamless integration with your system in just moments.
The device-independent solution works directly in your smartphone’s web browser and requires no app installation. This ensures that the ANB-P is ready for seamless integration with your building automation system in just a few moments.
Datasheet ANB-P
Manual ANB-P
OEM Bacnet Sensor
Andivi BACnet Sensors can be delivered as OEM sensors, allowing companies to embed them seamlessly into their product portfolios and systems while maintaining full compatibility with standardized protocols.
We offer the following OEM services:
- Custom product labeling featuring your logo and product number.
- Customized packaging labels, including your logo and product number.
- Datasheet customization with your branding and logo.
- Web App adjustment with your logo, color palette and brand identity,
- “Protocol Lock” – Locking the sensor to one of the selected communication protocols BACnet IP, BACnet MSTP, Modbus RS485.
